JETRIX KX7 series, coming with reliable quality, productivity and functionality
for the various application with the double heads function with the special UV inks for faster drying
and better adhesion on your wide format print-work with a beautiful color gamut.

Generic placeholder image

Head Part

Generic placeholder image

Flatbed Part

Generic placeholder image

Anti head crash Part

Generic placeholder image

Ink Refill Part

Generic placeholder image

Vacuum Part

Responsive image
Responsive image
Responsive image

SPECIFICATION

MODEL KX7
Size 4,220(W) x 4,030(D) x 1,440(H) mm
Weight 2,600kg
Footprint 5,000(W) x 4,600(D) mm

MODEL KX7-R
Size 4,220(W) x 4,535(D) x 1,440(H) mm
Weight 3,000kg
Footprint 5,000(W) x 5,100(D) mm

PRINTER WIDTH / DIMENSIONS

Max Rigid Media Size 2,440 x 3,060 mm
Max Media Thickness 100 mm
Max Roll Media Width 2,190 mm

RIP Availability / Compatibility

Caldera, Onyx Rip Software


Head Channel (max 14ch.)

Configuration C, M, Y, K + W + Varnish/ Primer ( Double Heads )
Standard C, M, Y, K(Double heads), White(4heads)
Option Varnish or Primer (Double heads)

Power and other requirements

Electrical Requirement 380V, 3phase 4wire, 50 ~ 60Hz
Compressed Air Requirement Over 0.5MPa
