Carefully designed for stability and precision,
the printer offers optimal printing results on a wide variety of substrates.
The JETRIX LX5 features the new LED curing system,
which costs less to run due to its lower energy consumption and longer lifetime.

Generic placeholder image

Head Part

Generic placeholder image

Flatbed Part

Generic placeholder image

LED lamp Part

Generic placeholder image

Vacuum Part

Generic placeholder image

Anti head crash Part

Responsive image
Responsive image
Responsive image

SPECIFICATION

MODEL LX5
Size 4,220(W) x 2,200(D) x 1,440(H) mm
Weight 1,150kg
Footprint 5,000(W) x 2,500(D) mm

MODEL LX5-R
Size 4,220(W) x 2,775(D) x 1,440(H) mm
Weight 1,600kg
Footprint 5,000(W) x 3,000(D) mm

PRINTER WIDTH / DIMENSIONS

Max Rigid Media Size 2,440 x 1,220 mm
Max Media Thickness 100 mm
Max Roll Media Width 2,190 mm

RIP Availability / Compatibility

Caldera Rip Software

Head Channel (max 8ch.)

Configuration C, M, Y, K + W + Varnish/ Primer
Standard C, M, Y, K(Single head), White(Double heads)
Option Varnish and Primer (Single head)

Power and other requirements

Electrical Requirement 210 ~ 230V, Single phase, 50 ~ 60Hz
Compressed Air Requirement Over 0.5MPa
