JETRIX XER320
The JETRIX XER160 is a compact and affordable roll-to-roll UV printer designed for high-quality and high-resolution printing, delivering up to 3,600 dpi output using the Epson i3200 printhead technology.
Despite its small footprint, it offers excellent productivity with speeds up to 42§³/h and supports roll media up to 1,600 mm wide and up to 60 kg. Equipped with automatic feeding, front & rear heating, and precise servo-driven control, it ensures stable media handling, minimises curling, and maintains consistent print quality.
Its Nozzle Detection Technology provides automatic laser-based nozzle blockage detection and compensation, reducing downtime and ensuring reliable output.
Powered by the Epson i3200 (5pl, micro-TFP), the XER160 is capable of producing crisp, band-free images, printing even 2pt small text with clarity. This makes it an excellent choice for businesses seeking a high-resolution, cost-effective roll-to-roll UV printing solution without compromising performance.
Features
-
High-resolution printing up to 3,600 dpi -
Epson i3200-U1 printheads (5pl, PrecisionCore MicroTFP)
-
Nozzle Detection Technology
-
Auto feeding & take-up system
-
Front & rear heating with heating wires to prevent media curling
-
White ink circulation system
-
Compact, user-friendly, cost-effective design
Specifications
- Size: 1,600 mm width × unlimited length / Up to 3 mm thickness
- Speed: Up to 42 m²/h
- Colours: C M Y K W V
- Resolution: Up to 3,600 dpi
