Compare Model



Productivity

Top speed	74 m²/h	130 m²/h	222 m²/h
Production	37 m²/h	75 m²/h	116 m²/h
Quality	25 m²/h	54 m²/h	78 m²/h
Fine Art	19 m²/h	41 m²/h	60 m²/h

Demensions

Flatbed, Full bleed	2500 × 1220 mm	2550 × 1270 mm	3200 × 2050 mm
Material clearance	Max. 100 mm	Max. 100 mm / Roll Max. 3 mm	Max. 100 mm
Substrate weight	Max. 100 kg/m²	Max. 100 kg/m² / Roll Max. 80 kg/m²	Max. 100 kg/m²
Roll option

Colours

Channels	Max. 7	Max. 8	Max. 8
Print heads	Max. 14	Max. 16	Max. 16
Print heads per channel	Max. 1 or 2	Max. 1 or 2	Max. 1 or 2
Light cyan / Light magenta
White
Primer, Varnish

Resolution

Addressable resolution

Up to 1440 dpi

Up to 1440 dpi

Up to 1440 dpi

Dimensions & Weight

Dimensions (W × D × H)	5100 × 2160 × 1610 mm	4820 × 2100 × 1560 mm	5530 × 3200 × 1580 mm
Weight	1962 kg	1600 kg	1950 kg
Roll option		3326 × 535 × 975 mm 630 kg
