The new JETRIX RX3200 is a high speed 3.2m Roll to Roll UV printer designed for maximum
productivity and a high precision concept. It comes equipped with KONICA KM1024 (14PL) print heads
and achieves outstanding print quality of up to 1440dpi. InkTec’s unique UV ink gives excellent adhesion and vibrant colors.

Generic placeholder image

16 units of KONICA
KM1024(14PL) Heads

Generic placeholder image

Automated head cleaning &
capping system

Generic placeholder image

Easy winding system
for heavy media by air shaft

Generic placeholder image

Mesh Print
Function

Generic placeholder image

Curing by
Honle UV Lamp

Responsive image
Responsive image
Responsive image

SPECIFICATION

Size 6,420(W) x 1,480(D) x 1,760(H) mm
Weight 3,540kg
Footprint 9,400(W) x 4,700(D) mm

PRINTER WIDTH / DIMENSIONS

Max Roll Media Width 3,200 mm
Max Media Thickness 10 mm

RIP Availability / Compatibility

Caldera, Onyx Rip Software


Head Channel (16ch.)

Configuration
Standard 4 color print in C, M, Y, K
Option 8 color print in C, M, Y, K, LC, LM, LY, LK (Switchable)

Power and other requirements

Electrical Requirement 3Phase 4Wire/ 380V/ 50~60Hz/ 50A (Required: 45KVA AVR)
Compressed Air Requirement Over 0.5MPa
